Introduction

In industrial machinery design, optimizing space utilization and cost efficiency are paramount. Our latest innovation—Bearings with Housings [Economy Model]—redefines these priorities through advanced engineering. Combining a revolutionary dual-fixing-hole design with high-integrity casting, this solution delivers unprecedented space savings and cost reductions while performance.

Key Innovations & Advantages

1. Ultimate Space Optimization

• Dual-Fixing-Hole System: Unlike conventional space-saving models, this bearing housing incorporates two strategically positioned fixing holes. This design minimizes footprint requirements by 18-22% compared to predecessors, enabling integration into tightly constrained assemblies (e.g., robotics arms, conveyor systems, and compact automation units).
• Streamlined Installation: The dual-hole configuration simplifies alignment during mounting, reducing assembly time by up to 30% while enhancing structural stability Through Precision Casting**
• Advanced Casting Technology: Manufactured via high-precision sand casting, these housings achieve near-net-shape accuracy. This eliminates extensive post-processing, reducing material waste by 40% and energy consumption by 25% versus milled alternatives.
• Economic Advantage: As-cast production yields up to 35% cost savings over traditional milled housings—without compromising on load capacity (rated for 5-7 kN static load) or corrosion resistance (standard: ASTM A48 Class 30 cast

1. Performance Reliability

• Integrated Bearing-Housing Design: Single-bearing units ensure optimal load distribution and misalignment tolerance (±0.5°), extending service life in high-vibration environments.
• Sealing Compatibility: Pre-machined grooves support standard seals (e.g., NAK, TTO), preventing contaminant ingress in dusty or humid conditions.

Target Applications

Ideal for industries prioritizing compactness and budget efficiency:

• Material Handling: Conveyor rollers, palletizers.
• **Agriculture &
• General Machinery: Pumps, fans, light-duty gearboxes.

Technical Specifications

| Parameter | Value |
|--------------------|---------------------------|
| Housing Material | ASTM A48 Class 30 Cast Iron |
| Bearing Type | Single-row ball bearing |
| Temperature Range | -20°C to +120°C |
| Protection Class | IP54 (standard) |
| Mounting | Bolt-on (dual-hole M8) |

Why Choose Our Economy Model? housing transcends conventional trade-offs:

• Space Savings + Cost Reduction: Achieve denser machine layouts while cutting component expenses.
• Sustainability: Lower carbon footprint via efficient casting and reduced machining.
• Scalability: Compatible with custom sizes (30-100mm bore) and bulk-order discounts.
